Conventional impact attenuators have a fatal flaw.

When a nuclear structure or transport cask experiences an impact event, traditional honeycomb energy absorbers deliver a violent initial stress spike—a sudden, uncontrolled force transmitted directly to the protected structure before the energy absorption mechanism fully engages.

This initial peak stress:

· Shocks the containment system beyond design limits

· Transmits excessive load to sensitive nuclear components

· Compromises the predictable crush response you depend on

· Creates uncertainty in accident scenario modeling

Wood-based fillers—still commonly used in nuclear impact limiters—exacerbate the problem with inconsistent mechanical properties across different directions, making it difficult to ensure uniform protection.

---

The Solution

Our Un-crushed Cross-Core Aluminum Honeycomb Impact Attenuator eliminates these uncertainties.

Two Breakthrough Innovations:

1. Un-crushed Cross-Core Architecture

Unlike pre-crushed or conventional honeycomb designs that suffer from localized collapse and unpredictable deformation bands, our cross-core configuration enables uniform, progressive crushing across the entire core. Every cell engages simultaneously—no weak spots, no surprise failures.

2. Initial Peak Stress Elimination (Optional)

The optional initial peak stress elimination feature fundamentally reshapes the impact response curve. By eliminating the characteristic stress spike at the onset of crushing, the attenuator delivers:

· Smooth, ramp-up energy absorption from the very first millisecond

· Predictable, flat plateau stress throughout the crush stroke

· Dramatically reduced transmitted force to the protected structure

---

Why This Matters for Nuclear Safety

Your Challenge Our Solution

Unpredictable impact loads on containment Eliminated initial peak stress = controlled, predictable force transmission

Wood filler variability across directions Bidirectional aluminum honeycomb with consistent mechanical properties in Y and Z axes

Uncertainty in accident consequence analysis Flat, repeatable crush response enables accurate modeling

Limited design space for impact limiters Higher energy absorption per unit volume than wood

Regulatory compliance (ASME, NRC, IAEA) Engineered for safety-related nuclear structures

---

Technical Features

Feature Benefit

Un-crushed cross-core Uniform deformation; no localized collapse

Initial peak stress elimination Zero stress spike; smooth energy absorption onset

Bidirectional structure Consistent performance in multiple loading directions

Aluminum honeycomb construction Lightweight; high specific energy absorption

Corrosion-resistant alloy Reliable in nuclear facility environments

Customizable crush strength Tailored to specific structural requirements

---

Performance Comparison

vs. Traditional Wood-Filled Impact Limiters:

Metric Wood Our Attenuator

Directional consistency Poor (anisotropic) Excellent (bidirectional)

Initial peak stress High and variable Eliminated (optional feature)

Energy absorption predictability Limited High (flat plateau stress)

Weight efficiency Moderate Superior

Environmental stability Moisture-sensitive Stable in all conditions

vs. Conventional Pre-Crushed Honeycomb:

Metric Pre-Crushed Honeycomb Our Attenuator

Deformation mode Localized bands Uniform cross-core crushing

Initial response Residual peak Smooth engagement

Design flexibility Limited Fully customizable

---

Applications

· Nuclear spent fuel transport cask impact limiters

· Safety-related nuclear structure impact protection

· Nuclear material shipping container shock absorption

· Nuclear power plant component impact attenuation

· Radioactive material packaging

---

Specifications (Typical)

Parameter Range

Material Aluminum alloy (corrosion-resistant)

Core configuration Cross-core, un-crushed

Crush strength Customizable to application

Operating temperature Broad range; suitable for nuclear environments

Peak stress elimination Optional (specify at order)

Certification Compliant with ASME BPVC Section III, Division 2 requirements

---

Why Choose Us

· Proven in nuclear applications—aluminum honeycomb impact limiters are extensively validated for nuclear waste transport

· Superior to wood—consistent, predictable, and reliable where wood fails

· Engineered for safety—designed specifically for safety-related nuclear structures

· Customizable—tailored crush strength and geometry to your specific requirements

Specifications:

Pasia Honeycomb Energy Absorbers can be supplied based on the cell size, foil thickness and layer, aluminum grade, width and length etc. The shape and parts can be also customized as per the request from client. The crush strength can be achieved on the performance of the foil thickness and special structure.

Testing Item: Aluminum Honeycomb Plain Crushing Strength

Testing Data

Testing Curve:
