Payment & Shipping Terms:
|Material:||A3003 Or A5052||Surface:||PVDF Powder Coated|
|Quality Guarantee Period:||15 Years||Size:||1220*2440 Mm2|
|Application:||Train Or Subway Wall||Thickness:||5mm, 12mm, 25mm|
aluminum honeycomb sheet,
aluminium honeycomb sandwich panel
PVDF Powder Coated Aluminium Honeycomb Panel for Train or Subway Wall
The PVDF material used for the aluminum honeycomb panel is to make the panel with a luxurious but rigid and anti-corrosion surface. The Powder Coating process will be versatile on the rail way products. The powder coating process will make the aluminum surface more artistic and nice looking. The PVDF powder coated aluminum honeycomb panel has been widely used more and more on train or subway wall panel, partition panel and so on. The weight is comparatively lighter than the same thickness FRP solid panel but with a similar strength with the FRP material. To save the energy and power, the modern train and subway require a lighter body but the strength should be the same or higher, therefore, powder coated aluminum honeycomb panel is becoming an ideal choice for this kind of application. The raw material, process and the final products of Pasia can completely meet or do better than the requirements of standard and code of International Union of Railways. Our products have been widely used by the Railway Industry home and abroad.
Aluminum honeycomb panel is a bonded sandwich structure system of two surface aluminium plates and one honeycomb cores with a special purpose adhesive. Industrial used aluminium honeycomb panel will add some more processes such as surface treatment, edging, embedding, carving and so on to make the panel suitable for special conditions. It has been widely used by the industries of civil construction, transportation, exhibition, signage, elevator, clean room etc. The honeycomb technology is from aerospace technology. The whole production process is finished in the modern factory, using hot pressing or vacuum pressing technology. Due to the high thermal conductivity between the aluminum plates and honeycomb, it is synchronized the thermal expansion and contraction of the inside and outside aluminium material. There are small holes on the honeycomb core foil wall so that the air is free of flowing inside the panel box. Furthermore, sliding mounting buckle system does not cause structural deformation during thermal expansion and contraction.
The center material is aluminum hexagonal honeycomb with a small density (about 3 to 7 kg per square meter), about 1/5 of the weight of wood with the same area and thickness, 1/6 of the glass, 1/7 of solid aluminium, which greatly reduced the building load and construction cost. Thanks to the air contained in the core, the panel can be sound and thermal insulated. Because of no combustible material contained, the fire rating can be at least B1 level. The panel performs well also on waterproof, moisture-proof, no harmful gas release, with a high unit mass of the specific strength and stiffness, not easy to deformation, completely overcoming the collapse and deformation in the center area if with large panel. The panel edge can be cut depending on real conditions. The PVDF coating can guarantee the product life more than 30 years.
After surface treated with corrosion resistant fluorocarbon resin, it can be widely used on curtain wall, roof, large façade, signs and interior decoration. The front plate of the aluminum honeycomb panel is painted with E. C. C. A. quality standards PVDF fluorocarbon paint with ordinary color or metallic color, so the surface has excellent weather resistance.
In case of heavy rain, there is particularly large noise when the raindrops hit the aluminum veneer or aluminum-plastic panel, while honeycomb panel can avoid this situation. Aluminum honeycomb panels are generally made of fluorocarbon coated aluminum plates. The continuous roller coating with PVDF material is the most important point to avoid color difference and flat coating film. Based on this, it can keep the exterior building with bright color for long time.
|Unit theory weight||kg/m2||5.4||5.6||5.75|
|Bend elasticity rate||N/mm2||50000||40600||38.44|
|Temeprature total extension coefficient||D696||X10-6N/℃||0.24||0.24||0.24|
|Heat conduction rate||D976||Kcal/mhr℃||0.23||0.19||0.15|
|Heat transform temperature||D648||℃||200||200||200|
|Surtace smoothness||1mm/M.Maximum deviation:1mm/M|
|Flame retardabt property||Nonflammable,match relevant fire resistance standard|
|Soundproof function||Be decided by layout of printed sheet installation angle,0-3dB|
(1) building external curtain wall panel
(2) interior decoration works
(4) ship building
(5) aviation manufacturing industry
(6) indoor partition and commodity display stand
(7) Commercial vehicle and container truck body
(8) bus, train and subway use
(9)With strict environmental requirements of the modern furniture industry, aluminum honeycomb panel is an ideal material to produce furniture. Depending on Its completely non-toxic green quality, it is not necessary for the furniture manufacturers to process environmental procedures. In addition, the surface veneer for aluminum honeycomb panels can be diversified such as solid wood, aluminum, gypsum board, natural marble etc
(10) aluminum honeycomb panel partition: the emergence of aluminum honeycomb panel partition breaks the traditional partition mode, with a noble and fresh style.
