| Material: | Basalt Stone Fiber | Diameter: | 13 Micron |
|---|---|---|---|
| Linear Density: | 2400 Tex | Sizing: | Silane |
| Application: | Weaving Or Filament Winding | Compatible With: | General Resin |
Basalt Fiber Roving for Weaving Geogrids Geotextiles and High Temperature Resistant Fabrics
Basalt continuous fiber roving is a high-performance reinforcement material manufactured from homogenized basalt rock through advanced pool kiln wire-drawing technology, directly formed by a 2400-hole large bushing. As a bundle of continuous unidirectional complex basalt fibers, this roving delivers exceptional mechanical strength, thermal endurance, and chemical resistance, making it the ideal choice for weaving applications including geogrids, geotextiles, and high-temperature resistant fabrics.
Key Features & Performance
· Superior Mechanical Properties – High tensile strength (≥0.65 N/tex) and high elastic modulus (≥95 GPa) provide specific tenacity exceeding steel fibers by multiple times. Low elongation under load ensures dimensional stability in demanding applications.
· Exceptional Thermal Resistance – Long-term service temperature ranges from –260°C to +680°C, with the ability to withstand short-term exposure up to 1000°C. Some variants maintain integrity at sustained temperatures up to 982°C (1800°F).
· Outstanding Chemical & Environmental Durability – Highly resistant to acids, alkalis, and solvents; immune to UV radiation, nuclear radiation, and biological contamination. Non-corrosive and inert in aggressive environments.
· Excellent Processability – Low fuzz and easy resin infiltration, compatible with a wide range of resin systems including epoxy (EP), phenolic, and others. Suitable for multi-axial weaving processes to produce complex fabric architectures.
· Eco-Friendly & Safe – Made from natural volcanic rock, non-toxic, with no carcinogenic risks.
Primary Applications
· Geogrids – Woven into high-strength geogrids for asphalt pavement reinforcement, offering strong competitive advantage at asphalt mixing temperatures up to 190°C. Improves durability and split-resistance of pavements.
· Geotextiles – Produces mesh fabrics and geotextiles for soil stabilization, erosion control, and infrastructure strengthening.
· High-Temperature Resistant Fabrics – Woven into fireproof textiles, thermal insulation fabrics, and protective clothing for extreme heat environments. Suitable for chevron cloth, mesh fabrics, and multi-axial fabrics.
· Additional Weaving Applications – Unidirectional fabrics, electrical insulation base cloth, needled felt base cloth, and radiation-resistant fabrics (650–980°C).
Key Product Identity:
| Parameter | Specification |
| Product Type | Direct Roving (Untwisted Continuous Strand) |
| Filament Diameter | 23 μm |
| Linear Density | 2400 tex |
| Sizing Type | Silane-based |
| Fiber Origin | Basalt Volcanic Rock |
| Production Method | Pool Kiln Wire-Drawing with Large Bushing |
---
2. Technical Specifications
2.1 Physical Properties
| Parameter | Value | Test Method |
| Filament Diameter | 23 μm | |
| Linear Density (Tex) | 2400 tex | |
| Density | 2.63 g/cm³ | DIN 65569 |
| Moisture Content | ≤ 0.1% | ASTM D570 |
| Sizing Content | ≥ 0.4% (minimum) | |
| Loss on Ignition | ≥ 0.40% | (varies with sizing) |
2.2 Mechanical Properties
| Parameter | Value | Test Method |
| Tensile Strength (Dry Fiber) | ≥ 0.65 N/tex | ASTM D3822 |
| Tensile Strength (Impregnated Strand) | 2,900 – 3,100 MPa | ASTM D2343 |
| Tensile Modulus | 86 – 90 GPa |
ASTM D2343
|
| Elongation at Break | ≥ 2.6% – 3.5% | ASTM D2343 |
| Tenacity (10-16 μm) | ≥ 650 mN/tex | ASTM D3822 |
Spcifications:
| Item No. | Linear Density(Tex) |
Tolerance (Tex) |
Sizing (%) |
Maximum Moisture (%) |
Diameter (μm) |
| PBFR7-FV-800 | 800 | ±64 | 0.4 | 0.2 | 7 |
| PBFR9-PP-1100 | 1100 | ±88 | 0.4 | 0.2 | 9 |
| PBFR9-PV-2400 | 2400 | ±192 | 0.4 | 0.2 | 9 |
| PBFR13-GC-1200 | 1200 | ±96 | 0.4 | 0.2 | 13 |
| PBFR13-GC-2400 | 2400 | ±192 | 0.4 | 0.2 | 13 |
Normally, direct roving is much better for filament winding, pultrusion and weaving fabrics.
| Property | Description |
| Type of fiber | Continuous basalt fiber |
| Monofilament diameter [µm] | From 9 to 31 |
| Linear density [tex] | 180-9600 |
| Type of sizing | Silane or starch |
| Sizing content (% wt.) | ≥0.4 |
| Resin compatibility | Polyester, vinyl ester, epoxy |
| Moisture content (% wt.) | <0.1 |
| Thermal Properties | |
| Melting Range: | 1460-1500°C |
| Crystalization temperature: | 1250°C |
| Sintering Temerature: | 1050°C |
| Thermal Conductivity, W/(m.K) | 0.031-0.038 |
| Tensile Strength Change by heating Pasia Basalt Fiber | |||
| Temperature | +20°C | +200°C | +400°C |
| Tensile Strength Change | 100% | 95% | 80% |
