Product Details:
Payment & Shipping Terms:
|
| Material: | Basalt Stone Fiber | Diameter: | 13 Micron |
|---|---|---|---|
| Linear Density: | 2400 Tex | Sizing: | Silane |
| Application: | Weaving Or Filament Winding | Compatible With: | General Resin |
High Tensile Strength 4800 MPa Basalt Fiber Roving Elastic Modulus Over 95 GPa Lightweight Reinforcement
Basalt continuous fiber roving is a high-performance reinforcement material manufactured from homogenized basalt rock through advanced pool kiln wire-drawing technology, directly formed by a 2400-hole large bushing. As a bundle of continuous unidirectional complex basalt fibers, this roving delivers exceptional mechanical strength, thermal endurance, and chemical resistance, making it the ideal choice for weaving applications including geogrids, geotextiles, and high-temperature resistant fabrics.
Our high-performance basalt fiber roving is a lightweight, continuous inorganic fiber reinforcement designed for advanced composite applications. With a tensile strength of 4800 MPa and an elastic modulus of over 95 GPa, it delivers excellent load-bearing capacity, stiffness, and dimensional stability while helping reduce overall component weight. It is compatible with epoxy, polyester, vinyl ester, phenolic, and other resin systems.
Key Features
· High tensile strength: 4800 MPa
· High elastic modulus: over 95 GPa
· Lightweight: low density, high specific strength and specific modulus
· Excellent corrosion and chemical resistance
· High thermal stability and non-combustibility
· Electrical insulation and non-magnetic properties
· Good resin wettability and interfacial bonding
· Durable, UV-resistant, and environmentally friendly
Typical Applications
· Aerospace and automotive lightweight structures
· Wind turbine blades and nacelles
· Pressure vessels, pipes, and storage tanks
· Construction reinforcement: rebar, grids, geogrids
· Marine and offshore composites
· Sports equipment, helmets, bicycle frames
· Electrical and thermal insulation components
Key Product Identity:
| Parameter | Specification |
| Product Type | Direct Roving (Untwisted Continuous Strand) |
| Filament Diameter | 23 μm |
| Linear Density | 2400 tex |
| Sizing Type | Silane-based |
| Fiber Origin | Basalt Volcanic Rock |
| Production Method | Pool Kiln Wire-Drawing with Large Bushing |
---
2. Technical Specifications
2.1 Physical Properties
| Parameter | Value | Test Method |
| Filament Diameter | 23 μm | |
| Linear Density (Tex) | 2400 tex | |
| Density | 2.63 g/cm³ | DIN 65569 |
| Moisture Content | ≤ 0.1% | ASTM D570 |
| Sizing Content | ≥ 0.4% (minimum) | |
| Loss on Ignition | ≥ 0.40% | (varies with sizing) |
2.2 Mechanical Properties
| Parameter | Value | Test Method |
| Tensile Strength (Dry Fiber) | ≥ 0.65 N/tex | ASTM D3822 |
| Tensile Strength (Impregnated Strand) | 2,900 – 3,100 MPa | ASTM D2343 |
| Tensile Modulus | 86 – 90 GPa |
ASTM D2343
|
| Elongation at Break | ≥ 2.6% – 3.5% | ASTM D2343 |
| Tenacity (10-16 μm) | ≥ 650 mN/tex | ASTM D3822 |
Spcifications:
| Item No. | Linear Density(Tex) |
Tolerance (Tex) |
Sizing (%) |
Maximum Moisture (%) |
Diameter (μm) |
| PBFR7-FV-800 | 800 | ±64 | 0.4 | 0.2 | 7 |
| PBFR9-PP-1100 | 1100 | ±88 | 0.4 | 0.2 | 9 |
| PBFR9-PV-2400 | 2400 | ±192 | 0.4 | 0.2 | 9 |
| PBFR13-GC-1200 | 1200 | ±96 | 0.4 | 0.2 | 13 |
| PBFR13-GC-2400 | 2400 | ±192 | 0.4 | 0.2 | 13 |
Normally, direct roving is much better for filament winding, pultrusion and weaving fabrics.
| Property | Description |
| Type of fiber | Continuous basalt fiber |
| Monofilament diameter [µm] | From 9 to 31 |
| Linear density [tex] | 180-9600 |
| Type of sizing | Silane or starch |
| Sizing content (% wt.) | ≥0.4 |
| Resin compatibility | Polyester, vinyl ester, epoxy |
| Moisture content (% wt.) | <0.1 |
| Thermal Properties | |
| Melting Range: | 1460-1500°C |
| Crystalization temperature: | 1250°C |
| Sintering Temerature: | 1050°C |
| Thermal Conductivity, W/(m.K) | 0.031-0.038 |
| Tensile Strength Change by heating Pasia Basalt Fiber | |||
| Temperature | +20°C | +200°C | +400°C |
| Tensile Strength Change | 100% | 95% | 80% |
