Product Details:
Payment & Shipping Terms:
|
| Foil Thickness: | 0.05mm | Size In Mm*mm: | 900*1500 |
|---|---|---|---|
| Surface Treated: | Anodized | Application: | Nuclear Power Plant |
| Product Name: | Energy Absorber | Thickness: | 25 Mm Or Customized |
Flame Resistant Crash Test Dummy Calibration Honeycomb Energy Absorber of Predictable Crush Profile
Pasia Industries, as a leading manufacturer of honeycomb energy absorbers, specialize in producing high-performance aluminum honeycomb cores that convert kinetic energy into controlled, predictable crushing forces.
Our Flame Resistant Honeycomb Energy Absorber is purpose-engineered for crash test dummy calibration—specifically the neck flexion/extension certification tests required under US Code of Federal Regulations (Part 572, Subpart E) and European ECE Regulations . These precision aluminum honeycomb blocks generate the controlled deceleration pulse essential for verifying Anthropomorphic Test Device (ATD) performance, ensuring repeatable, regulation-compliant calibration results.
The product combines predictable crush profile characteristics with flame-resistant material properties, making it suitable for testing environments where fire safety standards must be met.
Predictable Crush Profile – Engineered for Calibration Precision
The Science of Predictable Energy Absorption
When a load is applied to aluminum honeycomb, it undergoes plastic deformation through controlled cell wall buckling, converting kinetic energy into internal work at a constant force across the crushed thickness . This results in a linear, predictable force-displacement curve—the foundation of reliable dummy calibration.
Our energy absorbers deliver:
· Consistent crush strength tolerance within ±10% of rated value
· Crush stroke exceeding 70% of part thickness before densification
· Minimal rebound – virtually all impact energy converted to deformation, not returned to the system
· Elimination of peak loading via pre-crush option (static triggering)
Calibration Application Context
The neck extension/flexion test requires a precisely characterized deceleration pulse. As specified in ASTM F3016-14, the impactor nose must have zero stored energy before impact and no elastic rebound after impact . Aluminum honeycomb uniquely satisfies this requirement, providing a "crush and stop" behavior that foam or spring-based systems cannot replicate .
---
Flame Resistance – Safety Without Compromise
This product incorporates flame-resistant treatment or alloy selection appropriate for testing environments where:
· Aerospace cabin safety standards apply (FAA burn test requirements)
· Automotive test labs require fire-safe materials
· Defense and military testing protocols mandate flame retardancy
The flame-resistant properties do not compromise the predictable crush mechanics – the core retains its certified crush strength and deformation characteristics while meeting applicable fire safety classifications.
Specifications:
Pasia Honeycomb Energy Absorbers can be supplied based on the cell size, foil thickness and layer, aluminum grade, width and length etc. The shape and parts can be also customized as per the request from client. The crush strength can be achieved on the performance of the foil thickness and special structure.
| Density Range (pound per cubic foot) | Cell size range (diameter inch) | Alloy | Foil thickness (mm) | Foil layers |
| 1-10 | 1/8, 1/4, 3/8, 3/4, 3/16 etc | 3003/5052 | 0.04, 0.05, 0.06, 0.08, 0.1 | Single, double or triple |
| Sample Lot | Specification | D1.5-(0.05+0.05)-3003 | |
| Client | Standard | ||
| Required Value | Conclusion | Plain Crushing Strength: 9.6MPa | |
| Tested By | Time |
Testing Item: Aluminum Honeycomb Plain Crushing Strength
Testing Data
| Serial | Sample Name | Width(mm) | Length(mm) | Maximum Loading(N) | Crushing Strength(MPa) |
| Aluminum Honeycomb Core | 49.0 | 48.0 | 27487.99 | 9.70 | |
| Aluminum Honeycomb Core | 50.0 | 48.0 | 31790.69 | 9.57 | |
| Aluminum Honeycomb Core | 48.0 | 48.0 | 24778.45 | 9.59 | |
| Aluminum Honeycomb Core | 48.0 | 50.0 | 30205.60 | 9.52 | |
| Max Value | 50.0 | 50.0 | 31790.69 | 9.70 | |
| Min Value | 48.0 | 48.0 | 24778.45 | 9.52 | |
| X-bar | 48.8 | 48.5 | 28565.68 | 9.60 |
Testing Curve:
